What is a solargraph or solar pinhole camera?

A solargraph is a long-exposure pinhole camera — often a film can — that records the sun's path across the sky over days or weeks. This simulator shows the trail before you drill the hole or mount the can.

Can I simulate a solargraph in Guyana?

Yes. Defaults include Georgetown and other Guyana coordinates. Near the equator, sun paths are steep year-round; the simulator uses accurate ephemeris for your aim direction and exposure length.

How long should a solargraph exposure be?

Many makers run days to months. Longer exposures thicken the daily arcs and include more seasons. Preview different day counts here before committing paper and a can outdoors.

Tools

Free Solar Pinhole Camera Simulator

Aim a virtual can at the sky, set exposure days, and preview the sun trail burned onto paper — accurate to your latitude and aim.

Tap a section to expand settings

Focal length (f)Inner radius

⚠ Nominal — measure before building.

Diameter (∂)Wall (w)

Glossy emulsion faces the pinhole; enable Mirror for correct left↔right on the paper.

Mirror (emulsion / glossy side)Negative (paper)

Sky background

Can model

LatitudeLongitude

Start dateExposure days — 7

Step (min)Horizon cutoff (°)

Atmospheric refractionCloudy weather (broken / faded trails)

15°

30°

45°

60°

75°

paper FOV

pinhole / bore

paper FOVθ_vigboreDrag · pinch zoom
TrailsStartMidEnd

Bore azimuth90°

Bore altitude0° above horizonMid-height pinhole · bore normal to curved wall

Simulated paper

Cylindrical projection — paper wrapped on the inner wall, pinhole at mid-height (procedural sky). When the bore is tilted upward the horizon appears as a gentle curve near the lower edge. Trail brightness follows cos⁴θ falloff, airmass extinction, and soft bore vignetting. Shown inverted as the paper records it. 143 of 532 sun samples land on the 178 × 127 mm paper.

Optics

Slant f (pinhole→base): 85.0 mm; Blur reference on flat geometry
Preview scale (2R): 65.8 mm; Cylindrical paper at bore
Effective f: 85.0 mm; f − wall/2
f-number: f/177
Optimal pinhole (slant): 0.411 mm; 1.9·√(λf_eff)
Optimal pinhole (2R): 0.361 mm; For paper preview scale
Trail width (preview): 0.61 mm; max(sun disk, blur) at 2R
Sun disk (2R preview): 0.61 mm; 2R·0.53°
Capture width: ±77°; Azimuth (cylindrical)
Capture height: ±44°; Altitude at bore centre
Vignetting limit: 90°; θ_vig = atan(∂/w)

Pinhole size is close to optimal for the cylindrical preview scale.

The can stands upright on its flat base. The pinhole is at the centre of the curved wall (mid-height); compass and tilt aim the bore. Paper wraps the inner wall (cylindrical projection). f is the slant distance pinhole→base centre for blur calculations. Measure your container. Presets are nominal.

Real paper results

Solargraphy lesson

Frequently asked questions

What is a solargraph or solar pinhole camera?: A solargraph is a long-exposure pinhole camera — often a film can — that records the sun's path across the sky over days or weeks. This simulator shows the trail before you drill the hole or mount the can.
Can I simulate a solargraph in Guyana?: Yes. Defaults include Georgetown and other Guyana coordinates. Near the equator, sun paths are steep year-round; the simulator uses accurate ephemeris for your aim direction and exposure length.
How long should a solargraph exposure be?: Many makers run days to months. Longer exposures thicken the daily arcs and include more seasons. Preview different day counts here before committing paper and a can outdoors.

Plan a solargraph build with physics-based sun trails, field of view, and blur — then pair it with the Pinhole Optics Calculator for hole size and focal geometry.
